Multilayer PCB

  • Multilayer ENIG heavy copper PCB board
Multilayer ENIG heavy copper PCB board

Multilayer ENIG heavy copper PCB board

  • Material: FR4
  • Board Thickness: 1.6mm
  • Copper Thickness: 3oz
  • Surfase finish: Immersion gold
  • Description: Multilayer ENIG heavy copper PCB board
  • Inquiry

Multilayer ENIG heavy copper PCB board


Manufacturing  Capabilities
Features Capabilities
Layers 1  to  24 layers
Base Materials FR4, High TG FR4,CEM-3,CEM-1,Aluminum Base, Rogers,Halogen Free
Base Copper Thickness 0.5 oz to 5 oz
Finished Copper Thickness 1 oz to 5 oz
Board Thickness 0.2mm to 6.0mm
Maximum Panel Size 520mm x 1200mm
Finished Hole Size 0.1mm to 6.3mm
Hole Size Tolerance NPTH: ±0.05mm; PTH: ±0.076mm
Aspect  Ratio 8:01
Blind  or  Buried  Via Yes
Minimum  Trace  Width / Spacing 0.002" / 0.002"
Impendance Control Tolerance ±5%
Solder mask Type LPI
Solder mask / Silk screen Color Green, Black, White, Blue, Yellow, Red, etc…
Surface Finish Type HASL, HASL + Lead Free, Immersion Gold, Flash Gold, Immersion Tin,
Immersion Silver, OSP,
Carbon Ink Yes
Peelable Mask Yes
